FB100 SECTIONAL GARAGE DOOR OPERATOR

HOMEPAGE

1. Main functions:

l        Soft start and soft stop.

l        Unit has auto-reverse and auto-close function.

l        Door can be moved manually in case of power failure.

2.Main specification and technical parameters:

l        Power supply: AC220V±10%  50Hz/ 60Hz

l        Lift capacity: 20 Kg (9 teeth) / 15Kg (12 teeth)

l        Door speed: 5.77m per minute (9 teeth) / 7.7m per minute (12 teeth)

l        Motor: DC24V

l        Working time: 20s

l        The max. current of motor: DC24V, 8A

l        Bulb: AC220V, MAX 40W
