1.Technical specifications:
Model: 106 (AC) and 106(DC)
Power supply: 220VAC 50HZ
Motor's power: 90W 220VAC / 80W 24VDC
Max length of boom: 6m
Time for up/down: 2s( for 1~3M)
6s( for 4~6M)
Environment temperature: -20-50C
Protection class: IP44
2. Application:
Parking lots, toll gates, goods yards, railway crossings, commercial premises, apartment block access
3. Features:
1). Arms can be chosen from 3 meters to 6 meters.
2). BI-DIRECTION OF BOOM CLOSING,
The arm could fall down on the left or the right direction
3). Clutch key can be used to open the clutch when electricity is cut off.
4). All the process is soft without any noise and shaking.
5). Loop detector connection, IC system connection and the infrared sensor are reserved for the other functions.
6). Green light and red light are used here for indication the position of the beam.
|
